Data sheet:
1.Cutting speed:30~60cuts/minute
2.Finished paper length MAX 240mm
3.Finished paper width: 120-220mm
4.Finished paper height:80-100mm
5.Power supply:5kw 380V 50HZ 3 phase
6.Overall size:2800x1000x2000mm
7.Machine weight:1000KG
| Model | CIL-AS280 |
|---|---|
| Structure of machine | Wallboard |
| size of finished product(mm) | Customized |
| Machine type | cutting |
| Raw material type | hand towel log |
| Raw material gram | 14-40g |
| Cutting channel | single |
Feature and function:
1.When the paper can not be cut down,
the equipment will automatically stops and gives an alarm;
2.The high precision servo system is used in the feed motor servo system,
to ensure the quality of the finished product;
3.The equipment automatically calculate the quantity of the finished product being cut;
according to the raw material and the length of the finished product;
4.When data input is incorrect, the equipment breaks off and prompts to adjust on the interface;
5.The waste paper head and paper end can be automatically sorted;
6.The automatic sharpening knife system is used in the equipment,
can adjust the sharpening knife system according the requirement of paper being cut, which increase the cutting life;
7.The sharp steel wheel is used in the sharpening knife system, which increase the sharpening knife efficiency
